The auto-bagging unit is mainly used for the packing of the final material automatically

Type	Dimension(mm)			Power	Weight	Capacity	Area
	L	W	H	(KW)	(kg)	(T/h)	m2
ZDGB30	4900	1700	4500	1.5	1200	1.5-3	15



   The auto-bagging unit is mainly used for the packing of the final material automatically,meanwhile tamping the sack with four air cylinders for more material loading, and the auto-bagging unit can automatically transfers to the sack when the B sack A is full which can dramatically reduce the labor force.The main equipments contain packing collection,air compresser, pneumatic transport, material pipes and the electric control cabinet etc.



Technical advantage



1.Auto bagging
Delivery over the material after the fan automatically poured into the space package, and
can automatically switch between two rack, save labor, increase transportation efficiency.
2.Including Vibration system
Equipped with cylinder vibration suspension material rolling rack space package, in
charge at the same time automatically stocky materials, the Space package with this system
than ordinary irrigation kits rack loaded more than 20% of materials, saving space package
alsoreduce the transportation cost expenditures.
